Advantech 96PSA-A60W12R1-1 FSP DC 12V 5A 60W AC Adaptor
Full range AC input 90V~264V Meet Energy Star EPS 2.0 /ErP Lot 7 No load Power Consumption …0.21W High Reliability Available for high altitude(5,000M) and DOE level VI Output Power 60W Output Voltage & Current 12VDC@5A Efficiency (%) 88% minimum Dimension (L x W x H) 110x62.2x31.3mm Vibration 1g²/Hz at 10500 Hz MTBF 100,000 hours at 25°C Operating Temp. (°C) 0 to + 40°C Safety & EMC Class B Max Temp. (‹C) @ Load 70C — 80% Safety Standard CUL (UL 60950) / CB (IEC 60950) / CCC / CE / FCC / GS (EN 60950) / KC / RCM / Jug cord input DC Jack 5.5mm outer, 2.5mm inner
- Brand: Advantech
- Category: Power Supplies
- SKU: AT9887
- MPN: 96PSA-A60W12R1-3
Advantech 96PSA-A60W12R1-1 FSP DC 12V 5A 60W AC Adaptor
Click or hover over image to enlarge
Price on Application
Contact us for pricing
Sales will confirm current pricing and availability before order.
Available On Order
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
Advantech 96PSA-A60W12R1-1 FSP DC 12V 5A 60W AC Adaptor
Full range AC input 90V~264V Meet Energy Star EPS 2.0 /ErP Lot 7 No load Power Consumption …0.21W High Reliability Available for high altitude(5,000M) and DOE level VI Output Power 60W Output Voltage & Current 12VDC@5A Efficiency (%) 88% minimum Dimension (L x W x H) 110x62.2x31.3mm Vibration 1g²/Hz at 10500 Hz MTBF 100,000 hours at 25°C Operating Temp. (°C) 0 to + 40°C Safety & EMC Class B Max Temp. (‹C) @ Load 70C — 80% Safety Standard CUL (UL 60950) / CB (IEC 60950) / CCC / CE / FCC / GS (EN 60950) / KC / RCM / Jug cord input DC Jack 5.5mm outer, 2.5mm inner
Price on Application
