ATEN DP HDBASET-LITE EXTENDER
Networking > Network Accessories
- Brand: ATEN
- Category: Networking
- SKU: VE901-AT-U
- MPN: VE901-AT-U
ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m
ATEN DisplayPort HDBaseT-Lite Extender 4K/40m;1080p/70m, 4096 x 2160 pixels, AV transmitter & receiver, 70 m, Wired, Black, HDCP
Click or hover over image to enlarge
Operating voltage (transmitter)
5 V
Operating voltage (receiver)
5 V
Power consumption (TX)
2.84 W
Power consumption (RX)
5.72 W
Type
AV transmitter & receiver
Maximum resolution
4096 x 2160 pixels
Cable types supported
Cat5e, Cat6, Cat6a
Maximum transfer distance
70 m
Price on Application
Contact us for pricing
Sales will confirm current pricing and availability before order.
Available On Order
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
ATEN DP HDBASET-LITE EXTENDER
1x VE901T DisplayPort HDBaseT-Lite Transmitter
1x VE901R DisplayPort HDBaseT-Lite Receiver
2x 0AD8-1F05-26M1 Power Adapters
1x User Instructions
Key features
- Type: AV transmitter & receiver
- Maximum resolution: 4096 x 2160 pixels
- Cable types supported: Cat5e, Cat6, Cat6a
- Maximum transfer distance: 70 m
- LED indicators: Yes
- Supported video modes: 1080p
- Supported graphics resolutions: 3840 x 2160, 4096 x 2160
- Bandwidth: 10.2 Gbit/s
- Bandwidth: 297 MHz
- HDCP: Yes
- Material: Metal
- Rack mounting: Yes
- Plug and Play: Yes
- Impedance: 100 Ω
- HDCP version: 1.4
- Product colour: Black
- HDBaseT certified: Yes
- Connectivity technology: Wired
- RJ-45 input ports: 1
- RJ-45 output ports: 1
- HDBaseT port: Yes
- DisplayPorts in: 1
- DisplayPorts out: 1
- DC-in jack: Yes
- Operating voltage (transmitter): 5 V
- Operating voltage (receiver): 5 V
- Power consumption (TX): 2.84 W
- Power consumption (RX): 5.72 W
- Operating temperature (T-T): 0 - 40 °C
- Storage temperature (T-T): -20 - 60 °C
+ 19 more — see the Specifications tab.
Price on Application
