DYNAMIX Cat6 UTP Keystone Slimline Tooless & Punch Down Compatible
Cat6 UTP Keystone Slimline Tooless & Punch Down Compatible Jack White
- Brand: Dynamix
- Category: Tools & Installation
- SKU: FP-C6-TLWH
- MPN: FP-C6-TLWH
DYNAMIX Cat6 UTP Keystone Slimline Tooless & Punch Down Compatible
DYNAMIX Cat6 UTP Keystone Slimline Tooless & Punch Down Compatible Jack. 180 Dual IDC 23~26AWG. Colour White
Click or hover over image to enlarge
Spec
PRODUCT SPECIFICATIONS
Wiring
T568A & T568B
Compliance
Standard ANSI/TIA 568 C.2, ISO/IEC 11801: 2011 (Ed 2.2), IEC60603-7-4: 2010 (Ed 2.0), EN 50173-1: 2011, EN 50173-2: 2007including amendment A1: 2010, ANSI/TIA-568-C.2: 2009, IEC60512-99-001: 2012 (Ed 1.0)
Life cycles
Jack: 750 minIDC: Suitable for 23 - 26AWG stranded and solid wire,Compatible with both 110 & krone punch down toolTooless: When using the IDC CAP for wire management
Insertion force
20N Max
Retention strength
7.7kg between jack and plug
Operating temperatures
-10°C ~ 60°C
Price on Application
Contact us for pricing
Sales will confirm current pricing and availability before order.
In Stock
Shipped to your region. Freight is calculated at checkout from live courier rates.
Standard delivery to main‑centre, ground‑floor addresses is included in the quoted rate. For rural or oversized deliveries, any extra freight will be confirmed before dispatch.
Collection available — we'll confirm pickup readiness after your order:
- 136 Cryers Road, East Tāmaki, Auckland 2013
