StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter
StarTech.com Dual mSATA SSD to 2.5” SATA RAID Adapter Converter, SATA, mSATA, Black, Green, 5101299 h, CE, FCC, JMicron JMS562
Click or hover over image to enlarge
Brand:StarTech.com
MPN:2634113
Part #: 2634113
Internal
Yes
Product colour
Black, Green
Mean time between failures (MTBF)
5101299 h
Hot-swap
No
Certification
CE, FCC
Chipset
JMicron JMS562
Data transfer rate (max)
6 Gbit/s
RAID levels
0, 1, BIG, JBOD
Comsys Pacific Price
$38.99
Save NZ$5.00 off RRP
Out of Stock
Contact us for ETA or alternatives
NZ-wide deliveryNZ Post rates·Ships from Auckland, 1–3 days
Four payments of NZ$11.21 per fortnight
Value Deal
Fast dispatch and fair pricing on every order. Found a better offer? Ask for a match.
Secure Checkout
Trusted payment methods and encrypted transactions.
Technical Support
Pre-sales and post-sales support from our team.
Warranty Backed
Local warranty handling and straightforward returns.
StarTech.com Dual mSATA SSD to 2.5 SATA RAID Adapter
Vastly increase system performance by adding a dual mSATA SSD RAID array into any 2.5" SATA HDD application with the 25SAT22MSAT mSATA to SATA adapter.
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs
Utilize the full potential of your SATA III controller, with mSATA SSDs reducing your data transfer bottleneck with file transfer speeds up to 6 Gbps. mSATA SSDs also save you money by reducing your power consumption over regular platter drives.
You can achieve greater SSD capacity, or data redundancy with the Dual SSD controller supporting multiple RAID modes (RAID 0, 1, BIG). The SSD adapter also supports non-RAID operation (JBOD) when paired with a port-multiplying SATA controller, so both drives can be used independent of one another.
Help protect the health of your drive with an open-frame design ensuring maximum heat dissipation.
The 25SAT22MSAT is backed by a StarTech.com 2-year warranty, and lifetime technical support.
The StarTech.com Advantage
- Maximize system speed by adding SSD performance
- Achieve greater drive capacity, or secure data redundancy with multiple RAID modes
- Reduce overall power consumption, with high efficiency mSATA SSDs
Key features
- Host interface: SATA
- Output interface: mSATA
- SATA revision: 3.0
- Port multiplier: Yes
- Internal: Yes
- Product colour: Black, Green
- Mean time between failures (MTBF): 5101299 h
- Hot-swap: No
- Certification: CE, FCC
- Chipset: JMicron JMS562
- Data transfer rate (max): 6 Gbit/s
- RAID levels: 0, 1, BIG, JBOD
- Plug and Play: Yes
- Operating temperature (T-T): -40 - 85 °C
- Windows operating systems supported: Yes
- Mac operating systems supported: Yes
- Linux operating systems supported: Yes
- Compliance certificates: RoHS
- Width: 70 mm
- Depth: 97 mm
- Height: 7 mm
- Weight: 39 g
- Mounting brackets included: Yes
- Quick installation guide: Yes
- Package width: 174 mm
- Package depth: 145 mm
- Package height: 32 mm
- Package weight: 107 g
- Harmonized System (HS) code: 84733020
